    ISO 9360-1 Heat And Moisture Exchangers (HMEs) For Humidifying Respired Gases In Humans-Calibration HME

    Ask Lasest Price
    Brand Name : KingPo
    Model Number : ISO 9360-1-Figure 6
    Certification : calibration cert
    Payment Terms : T/T
    • Product Details
    • Company Profile

    ISO 9360-1 Heat And Moisture Exchangers (HMEs) For Humidifying Respired Gases In Humans-Calibration HME

    ISO 9360-1 Anaesthetic and respiratory equipment –Heat and moisture exchangers (HMEs) for humidifying respired gases in
    humans –Part 1: HMEs for use with minimum tidal volumes of 250 ml

    ISO 9360-1-Figure 6 — Calibration HME
    Calibration HME (Figure 6) consisting of a housing containing 81 polyvinyl chloride (PVC) tubes arranged in a 9 *9 array, each with an internal diameter of 2 mm, an external diameter of 4 mm, and a length of 50 mm.
    Key
    1 81 tubings; ID = 2 mm, OD = 4 mm
    2 Male 22 cone
    3 Male 1 5 cone
    4 Female 15 cone
    All parts made of acrylic except tubings, which are made of PVC
    a Outside dimension, sides angled to fit


    Quality ISO 9360-1 Heat And Moisture Exchangers (HMEs) For Humidifying Respired Gases In Humans-Calibration HME for sale
